Laboratory autoclave vertical {msi-41}
- Home
- Our Products
- Autoclave
- Laboratory autoclave vertical {msi-41}
Technical Specification
- Double walled construction
- Fully made of Stainless. Steel 304.
- Lid is made of 10mm thick Stainless Steel is die pressed to domed shape.
- Lid ring is made of Stainless Steel 10mm thick.
- Inner chamber is made of 16 swg & bottom of 16 swg
- Exterior body is made of 22Swg mirror finished.
- Supporting flange is made of thick S.S. flat.
- Entire joint argon arc wielded & grounded to smooth bur free finish.
- The Autoclave is supported on the S.S. legs.
- Autoclave supplied with two safety valves, pressure gauge, steam release valve & S.S. basket & drain valve at bottom.
- All autoclaves are provided with paddle lifting arrangement. The Autoclave is hydraulically tested for one & half times the operating pressure.
- Pressure Range : 15 & 18 PSI
|
Working Size in Cms
|
Exterior Dimension in Cms
|
Volume Ltr.
|
Weight (kg)
|
Rating
|
No. of Basket
|
|---|---|---|---|---|---|
|
30 X 50
|
53 x 53 x 100
|
35
|
40
|
2500 W
|
1
|
|
35X 55
|
60 x 60 x 110
|
55
|
50
|
3000 W
|
1
|
|
45 X 60
|
65 x 65 x 120
|
95
|
65
|
4000 W
|
2
|
|
55 X 75
|
75 x 75 x 130
|
180
|
90
|
6000 W
|
2
|
Optional Accessories:
- Digital Temp Controller
- Electronic Digital Timer (o-99mts)
- Low water level cutt off device with suitable sensor for protection of heaters
- Vacuum breaker valve
