Technical Specification
- Triple walled construction.
- Inner made of Stainless Steel 304.
- Exterior made of Galvanized sheets powder coated.
- Gap between the walls filled with glasswool insulation.
- Fully insulated door with brass lock hinges & ceramic rope.
- Heating is by specially designed energy efficient inconnel Air heaters.
- Heaters are fitted on three sides (2 side + 1 bottom).
- Supplied with SS rod shelves & Aluminum ventilator.
- Microprocessor based Auto Tune PID Temperature Controller.
- Simplex A class transition joint Head type PT 100 sensor.
- Forced Air Circulating System with fan for temperature uniformity.
- Castor Wheels for easy movability.
- Temperature Range : 50.0°C to 400.0°C
- Temp Resolution : 0.1°C
- Control Accuracy : ± 2.0°C or better.
- Power Supply : 230V Single Phase AC
| CHAMBER SIZE IN CMS | VOLUME | EXTERIOR DIMENSION IN CMS | WEIGHT (KG) | RATING | NO OF SHELVES |
|---|---|---|---|---|---|
| 45 x 45 x 45 | 90 ltr | 85 x 85 x 110 | 70 | 2500 W | 3 |
| 60 x 60 x 60 | 216 ltr | 100 x 100 x 125 | 100 | 3500 W | 4 |
| 60 x 60 x 90 | 330 ltr | 100 x 100 x 155 | 120 | 4000 W | 5 |
Optional Accessories:
- Inbuilt timer
- Safety Controller (Recommended by us)
- Single channel Data logger to Print records
- RS 485 for PC communication with 21 CFR part 11 compliance Software
