Applications:
- Uses for digestion of media in Conical Flask (upto 2 ltr.).
- Water Level Indicating Device.
- Safety thermostatic cut-off for low water detection with visual indication.
Advantages:
- Avoid media solidification.
- Avoid media over boil.
Construction:
Mechanical
- Fully stainless steel 304 double walled construction with insulation for preventing energy losses.
- Hinged lid with assisted lift for easy opening as well as effortless closing & removal of racks.
- SS wiremesh basket cover for efficient steam movement and stable placement of media inside.
- Drain Valve
- Open port at top for venting of steam.
- Provided with validation port.
Electrical
- User selectable Digital Temperature Controller with Timer.
- Special energy efficient tubular heaters.
- Temperature range/Ambient +5 to 100°C.
- Accuracy: ±1°C.
- Resolution: 1°C.
Technical Data
| INTERNAL DIMENSION (WxDxH) / CAPACITY | HEATER | PRODUCT EXTERNAL DIMENSION (WxDxH) | PACKING |
|---|---|---|---|
| 400 x 300 x 200 mm / 24L | 1.5 kW | 600 x 440 x 450 mm | 0.24 m³ / 60 kg |
| 600 x 400 x 350 mm / 84L | 3.0 kW | 680 x 540 x 800 mm | 0.53 m³ / 90 kg |
| CAPACITY | D x H (MM) | STEAM FOR 400 x 300 x 200 | STEAM FOR 600 x 400 x 350 |
|---|---|---|---|
| Erlenmeyer Flask capacity 250 ml | 85 x 140 | 12 | 24 |
| Erlenmeyer Flask capacity 500 ml | 106 x 176 | 6 | 15 |
| Erlenmeyer Flask capacity 1000 ml | 131 x 220 | 0 | 12 |
| Erlenmeyer Flask capacity 2000 ml | 155 x 280 | 0 | 6 |
| Erlenmeyer Flask capacity 3000 ml | 155 x 315 | 0 | 6 |
| Erlenmeyer Flask capacity 5000 ml | 220 x 377 | 0 | 0 |
| Duram Bottles capacity 250 ml | 70 x 143 | 20 | 40 |
| Duram Bottles capacity 500 ml | 86 x 181 | 12 | 24 |
| Duram Bottles capacity 1000 ml | 101 x 230 | 6 | 15 |
| Duram Bottles capacity 2000 ml | 135 x 260 | 0 | 8 |
| Duram Bottles capacity 5000 ml | 186 x 310 | 0 | 6 |
