Technical Specification
- Double walled construction.
- Fully made of Stainless Steel 304 mirror finished
- Exterior Matt Finished.
- Gap between the two walls filled with PU insulation.
- Inner acrylic door & external metal door with magnetic gasket & lock.
- Cooling is by hermetically sealed compressor,
- CFC free refrigerant.
- Heating is by specially designed Air heaters.
- Forced Air circulating System with fan for better temperature uniformity.
- Microprocessor based Auto Tune PID Digital Temperature Controller
- Led display for Set & Actual both.
- Illumination by tube.
- Supplied with SS rod shelves.
- Temperature Range : 5.0°C to 60.0°C
- Humidity Range : 95% RH
- Temperature Resolution : 0.1°C
- Control Accuracy : ± 0.5°C
- Power Supply : 230V Single Phase AC
| CAPACITY (LTR) | CHAMBER SIZE (CMS) | EXTERIOR DIMENSION | NET WEIGHT (KG) | NO OF SHELVES | RATING |
|---|---|---|---|---|---|
| 6 Cu Ft 170 | 50 x 50 x 70 | 67 x 95 x 132 | 80 | 3 | 1250 W |
| 12 Cu Ft 330 | 60 x 60 x 90 | 77 x 105 x 152 | 110 | 4 | 1500 W |
| 16 Cu Ft 450 | 60 x 60 x 125 | 75 x 105 x 180 | 150 | 5 | 2000 W |
| 21 Cu Ft 600 | 60 x 80 x 125 | 75 x 125 x 180 | 200 | 5 | 2500 W |
Optional Accessories:
- Safety Temp. controller (Recommended by us)
- Single Channel Data logger with printer output
- RS 485 for PC communication with 21 CFR part 11 compliance Software
- 7” HMI touch screen display
